Mach 44 Bit

MACH 44 Specification

Part Number Bit Diameter Face Flushing Holes Guage Button Face Button Cone Button Weight
Suitable Hammer’s:
INCH MM Outer DiamxNos Inner DiamxNos Diam x Nos Diam x Nos Kgs
B05 04 107 01 4 1/8 107 Flat 2 14 x 8 12 x 6
B05 04 107 02 4 1/8 107 Concave 2 14 x 8 12 x 4 12 x 2
B05 04 107 03 4 1/8 107 Convex 2 14 x 8 12 x 4 12 x 2
B05 04 115 01 4.5 115 Flat 2 14 x 8 12 x 6
B05 04 115 02 4.5 115 Concave 2 14 x 8 12 x 4 12 x 2
B05 04 115 03 4.5 115 Convex 2 14 x 8 12 x 4 12 x 3
B05 04 121 01 4 3/4 121 Flat 2 14 x 8 12 x 7
B05 04 121 02 4 3/4 121 Concave 2 14 x 8 12 x 5 12 x 2
B05 04 121 03 4 3/4 121 Convex 2 14 x 8 12 x 4 12 x 3
B05 04 127 01 5 127 Flat 2 14 x 8 12 x 8
B05 04 127 02 5 127 Concave 2 14 x 8 12 x 5 12 x 3
B05 04 127 03 5 127 Convex 2 14 x 8 12 x 4 12 x 3
B05 04 133 01 5 1/4 133 Flat 2 14 x 8 12 x 10
B05 04 133 02 5 1/4 133 Concave 2 14 x 8 12 x 6 12 x 4
B05 04 133 03 5 1/4 133 Convex 2 14 x 8 14 x 6 12 x 4
B05 04 140 01 5.5 140 Flat 2 14 x 8 14 x 10
B05 04 140 02 5.5 140 Concave 2 14 x 8 14 x 6 14 x 4
